遇到的问题
https://pkmer.cn/Pkmer-Docs/10-obsidian/obsidian外观/css-片段/obsidian样式-minimal主题cards卡片布局/
在阅读模式下,list-card 可以渲染,但是在实阅模式下不能渲染
预期的效果
能在实阅模式下渲染
源代码
/* @settings
name: Minimal list-Cards
id: minimal-cards-style
settings:
-
id: cards-min-width
title: 卡片最小宽度
type: variable-text
default: 180px
-
id: cards-max-width
title: 卡片最大宽度
description: 默认填充可用宽度,接受有效的CSS单位
type: variable-text
default: 1fr
-
id: cards-mobile-width
title: 移动设备上卡片最小宽度
type: variable-text
default: 120px
-
id: cards-padding
title: 卡片内边距
type: variable-text
default: 1.2em
-
id: cards-image-height
title: 卡片最大图片高度
type: variable-text
default: 400px
-
id: cards-border-width
title: 卡片边框宽度
type: variable-text
default: 1px
-
id: cards-background
title: 卡片背景颜色
type: variable-themed-color
format: hex
default-light: '#'
default-dark: '#'
*/
body {
--cards-min-width: 180px;
--cards-max-width: 1fr;
--cards-mobile-width: 120px;
--cards-image-height: 400px;
--cards-padding: 1.2em;
--cards-image-fit: contain;
--cards-background: transparent;
--cards-border-width: 1px;
--cards-aspect-ratio: auto;
--cards-columns: repeat(auto-fit, minmax(var(--cards-min-width), var(--cards-max-width)))
}
@media(max-width:400pt) {
body {
--cards-min-width: var(--cards-mobile-width)
}
}
.cards.table-100 table.dataview tbody,
.table-100 .cards table.dataview tbody {
padding: .25rem .75rem
}
.cards table.dataview {
--table-width: 100%;
--table-edge-cell-padding-first: calc(var(--cards-padding)/2);
--table-edge-cell-padding-last: calc(var(--cards-padding)/2);
--table-cell-padding: calc(var(--cards-padding)/3) calc(var(--cards-padding)/2);
line-height: 1.3
}
.cards table.dataview tbody {
clear: both;
padding: .5rem 0;
display: grid;
grid-template-columns: var(--cards-columns);
grid-column-gap: .75rem;
grid-row-gap: .75rem
}
.cards table.dataview>tbody>tr {
background-color: var(--cards-background);
border: var(--cards-border-width) solid var(--background-modifier-border);
display: flex;
flex-direction: column;
margin: 0;
padding: 0 0 calc(var(--cards-padding)/3) 0;
border-radius: 6px;
overflow: hidden;
transition: box-shadow .15s linear;
max-width: var(--cards-max-width);
height: auto
}
.cards table.dataview>tbody>tr:hover {
border: var(--cards-border-width) solid var(--background-modifier-border-hover);
box-shadow: 0 4px 6px 0 rgba(0, 0, 0, .05), 0 1px 3px 1px rgba(0, 0, 0, .025);
transition: box-shadow .15s linear
}
.cards table.dataview tbody>tr>td:first-child {
font-weight: var(--bold-weight);
border: none
}
.cards table.dataview tbody>tr>td:first-child a {
display: block
}
.cards table.dataview tbody>tr>td:last-child {
border: none
}
.cards table.dataview tbody>tr>td:not(:first-child) {
font-size: calc(var(--table-text-size)*.9);
color: var(--text-muted)
}
.cards table.dataview tbody>tr>td>* {
padding: calc(var(--cards-padding)/3) 0
}
.cards table.dataview tbody>tr>td:not(:last-child):not(:first-child) {
padding: 4px 0;
border-bottom: 1px solid var(--background-modifier-border);
width: calc(100% - var(--cards-padding));
margin: 0 calc(var(--cards-padding)/2)
}
.cards table.dataview tbody>tr>td a {
text-decoration: none
}
.cards table.dataview tbody>tr>td>button {
width: 100%;
margin: calc(var(--cards-padding)/2) 0
}
.cards table.dataview tbody>tr>td:last-child>button {
margin-bottom: calc(var(--cards-padding)/6)
}
.cards table.dataview tbody>tr>td>ul {
width: 100%;
padding: .25em 0 !important;
margin: 0 auto !important
}
.cards table.dataview tbody>tr>td:has(img) {
padding: 0 !important;
background-color: var(--background-secondary);
display: block;
margin: 0;
width: 100%
}
.cards table.dataview tbody>tr>td img {
aspect-ratio: var(--cards-aspect-ratio);
width: 100%;
object-fit: var(--cards-image-fit);
max-height: var(--cards-image-height);
background-color: var(--background-secondary);
vertical-align: bottom
}
.markdown-source-view.mod-cm6.cards .dataview.table-view-table>tbody>tr>td,
.trim-cols .cards table.dataview tbody>tr>td {
white-space: normal
}
.links-int-on .cards table {
--link-decoration: none
}
.markdown-source-view.mod-cm6.cards .edit-block-button {
top: -1px;
right: 28px;
opacity: 1
}
.cards.table-100 table.dataview thead>tr,
.table-100 .cards table.dataview thead>tr {
right: .75rem
}
.cards.table-100 table.dataview thead:before,
.table-100 .cards table.dataview thead:before {
margin-right: .75rem
}
.cards table.dataview thead {
user-select: none;
width: 180px;
display: block;
float: right;
position: relative;
text-align: right;
height: 24px;
padding-bottom: 0
}
.cards table.dataview thead:hover:after {
background-color: var(--background-modifier-hover)
}
.cards table.dataview thead:hover:before {
background-color: var(--text-muted)
}
.cards table.dataview thead:after,
.cards table.dataview thead:before {
content: "";
position: absolute;
right: 0;
top: 0;
width: 10px;
height: 16px;
cursor: var(--cursor);
text-align: right;
padding: var(--size-4-1) var(--size-4-2);
margin-bottom: 2px;
border-radius: var(--radius-s);
font-weight: 500;
font-size: var(--font-adaptive-small)
}
.cards table.dataview thead:before {
background-color: var(--text-faint);
-webkit-mask-repeat: no-repeat;
-webkit-mask-size: 16px;
-webkit-mask-position: center center;
}
.cards table.dataview thead>tr {
top: -1px;
position: absolute;
display: none;
z-index: 9;
border: 1px solid var(--background-modifier-border-hover);
background-color: var(--background-secondary);
box-shadow: var(--shadow-s);
padding: 6px;
border-radius: var(--radius-m);
flex-direction: column;
margin: 24px 0 0 0;
width: 100%
}
.cards table.dataview thead:hover>tr {
display: flex;
height: auto
}
.cards table.dataview thead>tr>th {
display: block;
padding: 3px 30px 3px 6px !important;
border-radius: var(--radius-s);
width: 100%;
font-weight: 400;
color: var(--text-normal);
cursor: var(--cursor);
border: none;
font-size: var(--font-ui-small)
}
.cards table.dataview thead>tr>th[sortable-style=sortable-asc],
.cards table.dataview thead>tr>th[sortable-style=sortable-desc] {
color: var(--text-normal)
}
.cards table.dataview thead>tr>th:hover {
color: var(--text-normal);
background-color: var(--background-modifier-hover)
}
.list-cards.markdown-preview-view .list-bullet,
.list-cards.markdown-preview-view .list-collapse-indicator,
.list-cards.markdown-preview-view.markdown-rendered.show-indentation-guide li>ul::before {
display: none
}
.list-cards.markdown-preview-view div>ul {
display: grid;
gap: .75rem;
grid-template-columns: var(--cards-columns);
padding: 0;
line-height: var(--line-height-tight)
}
.list-cards.markdown-preview-view div>ul .contains-task-list {
padding-inline-start: calc(var(--cards-padding)*1.5)
}
.list-cards.markdown-preview-view div>ul>li {
background-color: var(--cards-background);
padding: calc(var(--cards-padding)/2);
border-radius: var(--radius-s);
border: var(--cards-border-width) solid var(--background-modifier-border);
overflow: hidden;
margin-inline-start: 0
}
.list-cards.markdown-preview-view div>ul .image-embed {
padding: 0;
display: block;
background-color: var(--background-secondary);
border-radius: var(--image-radius)
}
.list-cards.markdown-preview-view div>ul .image-embed img {
aspect-ratio: var(--cards-aspect-ratio);
object-fit: var(--cards-image-fit);
max-height: var(--cards-image-height);
background-color: var(--background-secondary);
vertical-align: bottom
}
.list-cards.markdown-preview-view div>ul>li>a {
--link-decoration: none;
--link-external-decoration: none;
font-weight: var(--bold-weight)
}
.list-cards.markdown-preview-view div ul>li:hover {
border-color: var(--background-modifier-border-hover)
}
.list-cards.markdown-preview-view div ul ul {
display: block;
width: 100%;
color: var(--text-muted);
font-size: var(--font-smallest);
margin: calc(var(--cards-padding)/-4) 0;
padding: calc(var(--cards-padding)/2) 0
}
.list-cards.markdown-preview-view div ul ul ul {
padding-bottom: calc(var(--cards-padding)/4)
}
.list-cards.markdown-preview-view div ul ul>li {
display: block;
margin-inline-start: 0
}
.cards.cards-16-9,
.list-cards.cards-16-9 {
--cards-aspect-ratio: 16/9
}
.cards.cards-1-1,
.list-cards.cards-1-1 {
--cards-aspect-ratio: 1/1
}
.cards.cards-2-1,
.list-cards.cards-2-1 {
--cards-aspect-ratio: 2/1
}
.cards.cards-2-3,
.list-cards.cards-2-3 {
--cards-aspect-ratio: 2/3
}
.cards.cards-cols-1,
.list-cards.cards-cols-1 {
--cards-columns: repeat(1, minmax(0, 1fr))
}
.cards.cards-cols-2,
.list-cards.cards-cols-2 {
--cards-columns: repeat(2, minmax(0, 1fr))
}
.cards.cards-cover,
.list-cards.cards-cover {
--cards-image-fit: cover
}
.cards.cards-align-bottom table.dataview tbody>tr>td:last-child,
.list-cards.cards-align-bottom table.dataview tbody>tr>td:last-child {
margin-top: auto
}
@media(max-width:400pt) {
.cards table.dataview tbody>tr>td:not(:first-child) {
font-size: 80%
}
}
@media(min-width:400pt) {
.cards-cols-3 {
--cards-columns: repeat(3, minmax(0, 1fr))
}
.cards-cols-4 {
--cards-columns: repeat(4, minmax(0, 1fr))
}
.cards-cols-5 {
--cards-columns: repeat(5, minmax(0, 1fr))
}
.cards-cols-6 {
--cards-columns: repeat(6, minmax(0, 1fr))
}
.cards-cols-7 {
--cards-columns: repeat(7, minmax(0, 1fr))
}
.cards-cols-8 {
--cards-columns: repeat(8, minmax(0, 1fr))
}
}
